Aluminum Leaf Guard Mesh
Gutter Guard Leaf Mesh is designed to prevent leaves and debris from entering gutters and downpipes. Aluminum Leaf Guard Mesh is particularly suited for gutter systems in areas with vast amounts of trees and shrubs. Gutter Guards are available in a range of materials and styles, mainly aluminum expanded mesh, stainless steel or HDPE mesh. Aluminum Leaf Mesh enjoys rust resistance, light weight and needs less maintenance compared with other metal mesh materials such as mild steel.
Aluminum Leaf Guard Mesh
Material: Aluminum, Stainless Steel
Finish: Powder coated
Color: black, gray, white, and etc.
Size: 5" × 48", 6" × 48", 7" and 8" sheet width also available.
Package: 5 pieces or 25 pieces per box.
Feature
Leaf Guard is locked on the gutter with special "locking" edge;
Easy installation;
Powder coated finish available against rust and corrosion;
Rigid material that will not break down under heavy ice and snow;
No damage for shingles when used for roof gutters;
Debris free water flow into gutters;
No blocked downpipes;
Debris free gutters with extended service life.
Application
Leaf Guard Products are mainly used as gutter guards against leaves, debris and vermin, to prevent the rainspouts and gutters from getting blocked.
Aluminum Expanded Mesh for Balcony Gutter Project Building
The mesh fits from the outside edge of the gutter across the gutter section and then is attached to the roof surface. This creates a platform that suspends leaves and debris above the balcony roof gutter.
Stainless Steel and Aluminum Mesh for Ground or Exterior Gutter Uses
Metal Mesh Gutter Guard 5" × 48" protects the gutters from becoming clogged with leaves and debris.
| Mesh Hole Type | Mesh size | Weight | Width | Length |
| Diamond | 6mm×6mm | 200g/m2 | 15cm-18cm | 6m or 8m |
| Square | 12mm×12mm | 200g/m2 |
| Diamond | 3.8mm×3.8mm | 660±30g/m2 | 1m×50m or custom size |
Advantages of Light Type Expanded Metal Plaster Mesh
Compared with the welded and woven wire mesh, the structure of expanded metal mesh is complete and stable, so it is easier to install and transport. Besides, unlike fiberglass cloth, expanded mesh has absolute flame retardancy, durability, resistance to harsh environment and water resistance.
Moreover, the expanded mesh is made by cutting and stretching, so there is no waste in its production process, which can save the product cost. Its price is also very competitive.
Application of Light Type Expanded Metal Plaster Mesh
Metal grates
Security fencing, walls, and doors
Racks and shelving
Strainers
Architectural infill panels
Satellite and radar antennas
HVAC systems
Partitions and equipment enclosures
Speaker grilles
Wind and machine guards
EMI/RFI shielding
Fluid and air filters
Feature of Light Type Expanded Metal Plaster Mesh
Simply fixed to the wall of water can plastering
Provide a smooth rounded edge for the corner
Easy to adjust to a variety of angles
One piece and single unit construction
Less weight and more economic than regular metal sheet
Extensive range of materials to suit any application
It is rigid for protective uses, while providing decorative effect
High quality for durable use
The most economical option among all metal materials
Easy to install
Specification of Light Type Expanded Metal Plaster Mesh
Pattern
Designation | LWD
inches
(mm) | SWD
inches
(mm) | Orig. Mat'l
Thickness
inches
(mm) | Strand
Width
inches
(mm) | Openings
per sq. in. |
| 500 | .405 - .506"
(10.25 - 12.75) | .143 - .279"
(3.6 - 7.1) | .003 - .04"
(.075 - 1) | .007- .07"
(.175 - 1.775) | 15-22 |
| 275 | .215 - .289"
(5.4 - 7.4) | .107 - .200"
(2.7 - 5.1) | .003 - .035"
(.075 - .9) | .005- .055"
(.125 - 1.4) | 33-77 |
| 190 | .180 - .190"
(4.5 -4.8) | .056 -.143"
(1.4 - 3.6) | .002 - .030"
(.05 - .75) | .005- .045"
(.125 - 1.1) | 79-166 |
| 125 | .112 - .160"
(3.0 - 4.06) | .055 -.115"
(1.4 - 2.92) | .002 - .026"
(.05 - .7) | .004- .04"
(.1 - 1.10) | 114-253 |
| 100 | .093 - .112"
(2.4 - 2.8) | .038 -.091"
(.97 - 2.3) | .002 - .025"
(.05 - .61) | .005- .026"
(.125 - .66) | 253-353 |
| 077 | .075 - .080"
(1.91 - 2.03) | .032 -.053"
(0.82 - 1.35) | .001 - .018"
(.025 - .46) | .004 - .020"
(.1 - .51) | 493-780 |
| 050 | .050 - 06"
(1.27 - 1.5) | .021 -.041"
(0.53 - 1.04) | .001 - .015"
(.025 - .381) | .004 - .015"
(.1 - .381) | 809-1814 |
| 031 | .03 - .04"
(0.78 - 1.02) | .021 -.029"
(0.53 - 0.74) | .001 - .005"
(.025 - .127) | .004 - .012"
(.1 - .31) | 1789-2942 |
| 020 | .020"
(0.51) | .011 -.014"
(0.28 - 0.36) | .001 - .002"
(.025 - .050) | .004 - .006"
(.1 - .152) | 8500-11000 |
